Specifications

Hardware

• Hardware Version
  V1

Interfaces

• Downlink Ports
  8 * 100Mbps RJ45 PoE Ports
• Uplink Ports
  2 * 100Mbps RJ45 Ports

PoE

• PoE Port
  Port 1 – 8
• PoE Standard
  802.3 af/at
• PoE Power Supply Type
  End-span
• PoE Pin Assignment
  1/2(+), 3/6(-)
• PoE Power
  30W Max. for each port,
  60W Max.
  for PoE power budget

Switch Property

• Standards and Protocols
  IEEE 802.3, IEEE 802.3u, and IEEE 802.3x
• Forwarding Mode
  Store and Forward
• Switching Capacity
  2 Gbps
• Packet Forwarding Rate
  1.49Mpps
• MAC Address Table
  2k
• Packet Buffer Memory
  448 K bit
• Jumbo Frame
  1.5 kB

Power Supply

• Input Power
  100-240 V AC 50/60 Hz
  1.5A max
• Power Consumption
  Idle: 5 W 100% Traffic
  Rate with PoE: 65 W

Physical Characteristics

• PWR
  On: The device power on is normal
  Off: the device is power off or failed
• PoE
  On: PoE is working
  Off: PoE not working
• DATA
  Blinking: Data transmission is active and working
• LED Indicators
  Max:
  When total PoE output power > Power Budget * 80%, the LED light will be on
  LNK/ACT:
  On: Data on TX/RX
  Off: Ports link down
• Fan Quantity
  Fanless
• Dimensions (W*D*H)
  167x99x33 mm
• Weight
  Net Weight: 0.47 kg
  Package Weight: 0.77 kg
• Installation
  Desktop

Button

• DIP Switch
  Default/CCTV (CCTV=250m Extend mode + VLAN mode)

Environmental

• Reliability
  Surge Immunity:
  IEC 61000-4-5
  Common mode ±4kV
  Differential mode ±2kV
  ESD Protection:
  IEC 61000-4-2
  Contact discharge ±6kV
  Air discharge ±8kV
• Operating Temperature
  -10°C to 55°C(14°F to 131°F)
• Operating Humidity
  10%~90% RH no condensation
• Storage Temperature
  -40°C to 70°C(-40°F to 158°F)
• Storage Humidity
  5%~90% RH no condensation

Others

• Certification
  CE, FCC, RoHS, UKCA, RCM
• Network Media
  10Base-T: Pair 2 Category 3 (cat 3) and above
  UTP / STP (≤100m)
  100Base-TX: Pair 2 Category 5 (cat 5) and above
  UTP / STP (≤100m)
