Camera

• Image Sensor
  1/2.8″ Progressive Scan CMOS
• Max. Resolution
  1920 × 1080
• Min. Illumination
  Color: 0.001 Lux @ (F1.0, AGC ON)
• Shutter Speed
  1/3 s to 1/100, 000 s
• Day & Night
  24/7 Color imaging
• Angle Adjustment
  Pan: 0° to 355°, tilt: 0° to 75°

Lens

• Lens Type
  Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV
  2.8 mm, horizontal FOV 105.2°, vertical FOV 56.5°, diagonal FOV 125.1°
  4 mm, horizontal FOV 83.6°, vertical FOV 46.2°, diagonal FOV 97.5°
• Lens Mount
  M12
• Iris Type
  Fixed
• Aperture
  F1.0

DORI

• DORI
  2.8 mm, D: 44.1 m, O: 17.5 m, R: 8.8 m, I: 4.4 m
  4 mm, D: 53.4 m, O: 21.2 m, R: 10.7 m, I: 5.3 m

Video

• Main Stream
  50 Hz: 25 fps (1920 × 1080, 1280 × 720)
  60 Hz: 30 fps (1920 × 1080, 1280 × 720)
• Sub-Stream
  50 Hz: 25 fps (640 × 480, 640 × 360)
  60 Hz: 30 fps (640 × 480, 640 × 360)
• Video Compression
  Main stream: H.265+/H.264+/H.265/H.264
  Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate
  32 Kbps to 8 Mbps
• H.264 Type
  Baseline Profile/Main Profile/High Profile
• H.265 Type
  Main Profile
• Region of Interest (ROI)
  1 fixed region for main stream

Network

• Protocols
  TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• Simultaneous Live View
  Up to 6 channels
• API
  Open Network Video Interface, ISAPI
• User/Host
  Up to 32 users. 3 levels: administrator, operator and user
• Client
  iVMS-4200, Hik-Connect
• Web Browser
  Plug-in required live view: IE 10+
  Plug-in free live view: Chrome 57.0+, Firefox 52.0+
  Local service: Chrome 57.0+, Firefox 52.0+


• Image Settings
  Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
• Day/Night Switch
  Day, Night, Auto, Schedule
• Wide Dynamic Range (WDR)
  Digital WDR
• Image Enhancement
  BLC, 3D DNR

Interface

• Ethernet Interface
  1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

• Basic Event
  Motion detection, video tampering alarm, exception
• Linkage
  Upload to FTP, notify surveillance center, send email, trigger capture

General

• Power
  12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
  PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
• Camera Material
  Metal & Plastic
• Camera Dimension
  Ø111 mm × 82.4 mm (Ø 4.4″ × 3.2″)
• Package Dimension
  134 mm × 134 mm × 108 mm (5.3″ × 5.3″ × 4.3″)
• Camera Weight
  Approx. 550 g (1.2 lb.)
• With Package Weight
  Approx. 800 g (1.8 lb.)
• Storage Conditions
  -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• Startup and Operating Conditions
  -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
• Language
  English, Ukrainian
• General Function
  Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Approval

• EMC
  FCC-SDoC: 47 CFR Part 15, Subpart B;
  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014;
  KC: KN 32: 2015, KN 35: 2015
• Safety
  UL: UL 62368-1;
  CB: IEC 62368-1: 2014+A11;
  CE-LVD: EN 62368-1: 2014/A11: 2017;
  BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005
• Environment
  CE-RoHS: 2011/65/EU;
  WEEE: 2012/19/EU;
  Reach: Regulation (EC) No 1907/2006
• Protection
  IP67: IEC 60529-2013
