Camera

• Image Sensor
  1/3″ Progressive Scan CMOS
• Max. Resolution
  2560 × 1440
• Min. Illumination
  Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0 Lux with IR
• Shutter Time
  1/3 s to 1/100,000 s
• Day & Night
  IR Cut Filter
• Angle Adjustment
  Pan: 0° to 355°, tilt: 0° to 70°, rotation: 0° to 355°

Lens

• Lens Type
  Varifocal Lens, motoried lens, 2.8 to 12 mm
• Focal Length & FOV
  2.8 to 12 mm: horizontal FOV 102° to 31°, vertical FOV 54° to 17°, diagonal FOV 123° to 35°
• Lens Mount
  Ø14
• Iris Type
  Fixed
• Aperture
  F1.6

Illuminator

• Supplement Light Type
  IR
• Supplement Light Range
  Up to 30 m
• IR Wavelength
  850 nm
• Smart Supplement Light
  Yes

Video

• Main Stream
  50 Hz: 20 fps (2560 × 1440)
  25 fps (1920 × 1080, 1280 × 720)
  60 Hz: 20 fps (2560 × 1440)
  30 fps (1920 × 1080, 1280 × 720)
• Sub-Stream
  50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
  60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
• Video Compression
  Main stream: H.265+/H.265/H.264+/H.264
  Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate
  32 Kbps to 8 Mbps
• H.264 Type
  Baseline Profile/Main Profile/High Profile
• H.265 Type
  Main Profile
• Region of Interest (ROI)
  1 fixed region for main stream

Audio

• Audio Compression
  -S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC
• Audio Bit Rate
  -S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC)
• Audio Sampling Rate
  -S: 8 kHz/16 kHz
• Environment Noise Filtering
  -S: Yes

Network

• Protocols
  TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• Simultaneous Live View
  Up to 6 channels
• API
  Open Network Video Interface, ISAPI
• User/Host
  Up to 32 users. 3 levels: administrator, operator and user
• Client
  iVMS-4200, Hik-Connect
• Web Browser
  Plug-in required live view: IE 10+
  Plug-in free live view: Chrome 57.0+, Firefox 52.0+
  Local service: Chrome 57.0+, Firefox 52.0+


• Image Settings
  Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• Day/Night Switch
  Auto, Schedule, Day, Night
• Wide Dynamic Range (WDR)
  120 dB
• Image Enhancement
  BLC, 3D DNR

Interface

• Ethernet Interface
  1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage
  Built-in memory card slot, support microSD card, up to 256 GB
• Audio
  -S:
  1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
  1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
• Alarm
  -S: 1 input,1 output, max. 12 VDC, 30 mA
• Reset Key
  Yes

Event

• Basic Event
  Motion detection, video tampering alarm, exception
• Linkage
  Upload to FTP, notify surveillance center, send email, upload to memory card, trigger recording, trigger capture

General

• Power
  12 VDC ± 25%, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug
  PoE: 802.3af, Class 3, 36 V to 57 V, 0.27 A to 0.17 A, max. 10 W
• Material
  Cover: plastic, main body: metal
• Dimension
  Ø129.4 mm × 116.4 mm (Ø5.1″ × 4.6″)
• Package Dimension
  170 mm × 170 mm × 150 mm (6.7″ × 6.7″ × 5.9″)
• Weight
  Approx. 560 g (1.2 lb.)
• With Package Weight
  Approx. 850 g (1.9 lb.)
• Storage Conditions
  -30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions
  -30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing)
• Language
  English, Ukrainian
• General Function
  Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Approval

• EMC
  FCC SDoC (47 CFR Part 15, Subpart B);
  CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
  RCM (AS/NZS CISPR 32: 2015);
  IC VoC (ICES-003: Issue 6, 2016);
  KC (KN 32: 2015, KN 35: 2015)
• Safety
  UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
  CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
  BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
• Environment
  CE-RoHS (2011/65/EU);
  WEEE (2012/19/EU);
  Reach (Regulation (EC) No 1907/2006)
• Protection
  IP67 (IEC 60529-2013)
