Motion Defection 2.0

• Human/Vehicle Analysis
  4-ch

Video and Audio

• IP Video Input
  8-ch
• HDMI Output
  1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz;1-ch, 4K（4096×2160）/30Hz，4K (3840×2160) /30Hz, 2K（2560×1440）/60Hz，1920×1080/60Hz，1600×1200/60Hz，1280×1024/60Hz，1280×720/60Hz; HDMI/VGA simultaneous output,;1-ch, 4K (3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; ,HDMI/VGA simultaneous output,
• VGA Output
  1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• Video Output Mode
  HDMI/VGA simultaneous output
• Incoming Bandwidth
  80 Mbps
• Outgoing Bandwidth
  80 Mbps
• Audio Output
  1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio
  1-ch, RCA (2.0 Vp-p, 1 k Ω)

Recording

• Stream Type
  Video, Video & Audio
• Audio Compression
  G.711ulaw/G.711alaw/G.722/G.726

Decoding

• Decoding Format
  H.265+,H.265,H.264+,H.264
• Decoding Capability
  1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps)
  *: The length or width of camera resolution (each track) cannot exceed 4096 pixels.
• Synchronous playback
  8-ch
• Recording Resolution
  8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF

Network

• Remote Connection
  32
• Network Protocol
  TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
• Network Interface
  1, RJ-45 10/100 Mbps self-adaptive Ethernet interface

PoE

• Interface
  8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
• Power
  ≤ 75 W

Auxiliary Interface

• Alarm In/Out
  N/A (4/1 is optional)
• SATA
  1 SATA interface
• Capacity
  Up to 8 TB capacity for each disk
• USB Interface
  2 × USB 2.0

General

• Power Supply
  48 VDC, 1.88 A
• Consumption
  ≤ 10 W (without HDD and PoE off)
• Working Temperature
  -10 to +55º C (+14 to +131º F)
• Working Humidity
  10% to 90%
• Dimension (W × D × H)
  320 × 240 × 48 mm (12.4″ × 9.4″ × 1.9″)
• Weight
  ≤ 1 kg (without HDD, 2.2 lb.)

Certification

• FCC
  Part 15 Subpart B, ANSI C63.4-2014
• CE
  EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
